WITA® SM 4.10 FR

WITA^® actuators are distinguished by a compact design, durability and versatility. The product is equipped with a reversible synchronous motor and a maintenance-free gear. Depending on the actuator type, the device is electrically connected via a lead or a terminal pre-assembled in the casing. The actuators are applied particularly in heating and air conditioningsystems, and can be used with 3-point controllers or switching contacts. Moreover, the product is available for DN15 to DN100 mixing valves.

Categories: Products, Drive technology, Servomotors,

SM 4.10 FR actuator with a built-in constant temperature controller has the same components as the SM 4.10 model. Its main functions include maintaining constant return temperature, controlling small areas or areas where it is necessary to maintain temperature at a constant level.The temperature is selected by a potentiometer placed next to the scale. Two LEDs indicate the actuator operating direction. You can select an operating mode by pressing a switch placed under the actuator casing. Furthermore, you can add remote control and room temperature measurement functions.
